Motion detector | Surface-mounted | 360°

Motion detector surface-mounted with 360° detection

A motion detector with infrared switch is a smart solution for automatically turning on lighting. This detector ensures that the light turns on immediately when motion is detected. Perfect for use in corridors, staircases, and other spaces where you often walk around with full hands. With its modern and stylish design, the motion detector fits well in any room.

The sensor has a detection range up to 6 meters at temperatures below 24°C and a 360° detection angle, so every movement from any direction is noticed. The connected lighting can be turned off via an adjustable timer (10 seconds to 15 minutes) when there is no motion. You can also set at which ambient light level the detector becomes active (3 to 2000 LUX). The motion detector consumes only 0.5 Watt, operates on 220-240V (AC) at 50/60 Hz, and offers reliable operation at speeds between 0.6 and 1.5 m/s.

Key features

• Full 360° motion detection
• Adjustable light sensitivity up to 2000 LUX
• Timer setting from 10 sec. to 15 min.
• Works at temperatures from -20°C to +40°C
• Ideal for dry spaces like corridors or offices

Product specifications

• Detection range: up to 6 meters (at < 24°C)
• Detection angle: 360 degrees
• Maximum load: 1000 Watt
• Timer: 10 sec. – 15 min. adjustable
• Operating voltage: 220–240V AC
• Frequency: 50/60 Hz
• Consumption: 0.5 Watt
• Ambient light sensitivity: adjustable from < 3 to 2000 LUX
• Detection speed: 0.6 – 1.5 m/s
• Operating temperature: -20°C to +40°C
• Humidity: < 93%
• Dimensions: Ø 115 mm x 22 mm
• IP rating: IP20
• Warranty: 2 years
• Packaging unit: 50 pieces
